Description
We supply you with filters of the highest quality for wire erosion, die-sinking erosion and spark erosion drilling.
This ensures a clean dielectric in the eroding process at all times.
- Use: Wire EDM and sinking EDM
- Packing unit: 2 Pcs.
Filter/5µm 340/46 x 450 mm
On request
Additional information
| Weight | 5,5 kg |
|---|---|
| Dimensions | 340 × 450 mm |
| Filter density | |
| Machines | Charmilles, Fanuc, Fanuc W0, Fanuc W1, Fanuc W2, Fanuc W3, Sodick, Sodick A750 WH, Sodick AQ-537 L, Sodick AQ-900L |
Technical data
| Machine type |
CHARMILLES, FANUC, SODICK
|
| Use | Wire EDM |
| Size | 340 / 46 x 450mm |
| Filter density | 3-5 µm |
| Flow | from inside |
| Filter Area | 10,5 m² |
| Pressure diffenrential | max. 3,0 bar |
| Packing unit | 2 Pcs. |
| Weight | 5,5 Kg/Pc. |
